Learn how to build a RAG application from data preparation and embeddings to retrieval, LLM integration, testing, security, and deployment.
Building a RAG application involves connecting an AI model to an external knowledge source so it can retrieve relevant information before generating an answer. The process typically includes defining the use case, preparing data, creating searchable knowledge chunks, implementing retrieval, connecting an AI model, adding security and guardrails, testing the system, and deploying it into production.
A simplified RAG development process looks like this:
Business Problem
↓
Knowledge Sources
↓
Data Processing
↓
Chunking
↓
Embeddings
↓
Knowledge Store
↓
Retrieval
↓
AI Model
↓
Testing & Guardrails
↓
Production Application
The important part is that RAG development starts with the business problem—not the AI model.
A RAG application is an AI-powered software application that retrieves information from external knowledge sources and uses that information to generate responses.
Unlike a basic AI chatbot that relies primarily on the model's existing capabilities, a RAG application can be connected to business-specific information.
For example, a company could build a RAG application using:
A user can then interact with that information through natural language.
Businesses often have valuable information spread across multiple systems.
Employees may spend time searching through:
A RAG application can provide a conversational interface over this information.
Instead of asking:
"Where is the document that explains our enterprise refund policy?"
an employee could ask:
"What is our refund policy for enterprise customers?"
The system can retrieve relevant information and generate an answer.
This can make organizational knowledge easier to access and use.
Before selecting a model or database, define the problem.
A weak starting point is:
"We want to build an AI chatbot."
A stronger starting point is:
"Our support team spends too much time searching product documentation before answering customer questions."
The second statement provides a measurable business problem.
RAG is particularly suitable for applications involving:
Not every piece of company information needs to be included.
Define the questions the system is expected to handle.
For example, a technical-support RAG application may need to answer:
This helps determine which data sources need to be connected.
Next, identify where the required information currently exists.
Possible sources include:
The architecture depends heavily on the type and quality of these sources.
Raw data usually cannot be sent directly into a RAG system.
It may contain:
A data-processing pipeline should identify and clean these issues.
For example:
Raw Documents
↓
Extraction
↓
Cleaning
↓
Normalization
↓
Metadata
↓
Ready for Indexing
Good RAG applications start with good knowledge.
Large documents need to be divided into manageable pieces.
These pieces are called chunks.
For example:
Product Manual
↓
Introduction
↓
Installation
↓
Configuration
↓
Troubleshooting
↓
API Reference
Each meaningful section can become one or more retrieval units.
If chunks are too small, important context can be lost.
If chunks are too large, retrieval may return too much unrelated information.
The goal is to preserve meaningful context while making retrieval precise.
Metadata can make retrieval significantly more useful.
A chunk could contain metadata such as:
Document: Enterprise Product Manual
Section: Authentication
Product: Enterprise Platform
Version: 4
Department: Engineering
Access Level: Internal
This information can help the retrieval layer determine which content should be returned.
Metadata can also support permission controls and filtering.
The next stage is creating embeddings for the knowledge chunks.
Embeddings represent the semantic meaning of text in a numerical form.
For example:
"How can I recover my account?"
and:
"I lost access to my account. What is the recovery process?"
may use different words while expressing a similar intent.
Semantic embeddings allow the retrieval system to identify these relationships.
The embeddings and document chunks need to be stored somewhere that supports efficient retrieval.
Depending on the application, you might use:
The right choice depends on:
There is no single database that is automatically best for every RAG project.
Now the application needs to answer a critical question:
Which information should be provided to the AI model for this particular user query?
The retrieval layer searches the knowledge base and returns relevant content.
A basic flow might look like:
User Query
↓
Query Embedding
↓
Vector Search
↓
Top Relevant Chunks
More advanced systems may use:
User Query
↓
Query Processing
↓
Keyword Search + Vector Search
↓
Metadata Filtering
↓
Re-Ranking
↓
Best Context
Pure semantic search is not always sufficient.
Imagine a developer asks:
"What does error code AUTH-403 mean?"
Exact keyword matching can be extremely useful here.
Another user might ask:
"Why can't I access my account after changing my credentials?"
Semantic search may be more useful for this type of question.
A hybrid retrieval system can combine both approaches.
Keyword Search
+
Semantic Search
↓
Combined Results
↓
Ranking
This can improve retrieval across different query types.
Initial retrieval may return several potentially relevant chunks.
A re-ranking layer can evaluate those results and prioritize the most useful ones.
For example:
Initial Retrieval
↓
20 Candidate Chunks
↓
Re-Ranking
↓
Top 5 Chunks
↓
LLM Context
This helps prevent the model from receiving excessive irrelevant information.
Once the relevant context has been retrieved, it can be passed to the AI model.
Conceptually:
System Instructions
+
User Question
+
Retrieved Context
↓
Language Model
↓
Generated Answer
The model can then use the retrieved information when generating its response.
The prompt should clearly explain how the model should use the retrieved information.
For example, the system may instruct the model to:
The prompt should support the application's specific requirements.
One useful feature of RAG applications is the ability to show where an answer came from.
For example:
"Enterprise customers can request a refund according to the applicable terms."
The application could provide:
Source: Enterprise Subscription Policy → Refund Terms
This allows users to verify the information themselves.
Source visibility is particularly valuable for:
This is one of the most important considerations for enterprise RAG.
Imagine a company has:
The AI should not retrieve information simply because it exists in the knowledge base.
The retrieval system should respect the user's permissions.
Conceptually:
User
↓
Authentication
↓
Permissions
↓
Allowed Knowledge
↓
Retrieval
↓
AI Response
Security should therefore be part of the architecture from the beginning.
A production RAG application needs to know what to do when the required information cannot be found.
For example:
"I couldn't find this information in the available documentation."
This is often better than generating a confident but unsupported answer.
Depending on the use case, the system could then:
A reliable AI system needs a well-designed failure path.
Guardrails define boundaries around the AI system.
They can help control:
For high-impact workflows, human approval can be added before sensitive actions are performed.
Testing only the final answer is not enough.
Suppose the AI produces an incorrect answer.
There are several possible causes:
Wrong Answer
↓
Was the source wrong?
↓
Was the wrong chunk retrieved?
↓
Was relevant context missing?
↓
Did the model misinterpret the context?
Evaluation should therefore examine the entire RAG pipeline.
Useful areas to measure include:
A RAG application should be tested using realistic questions.
Create a test dataset containing:
Questions with obvious answers.
Questions requiring contextual understanding.
Questions requiring multiple pieces of information.
Questions where the knowledge base contains no answer.
Questions involving documents with different versions or policies.
Questions involving information that some users should not access.
This produces a more realistic evaluation of the application.
Launching a RAG application is not the end of development.
Monitor:
Over time, real user queries can reveal weaknesses that were not visible during initial testing.
One major advantage of RAG is that knowledge can often be updated separately from the underlying language model.
A typical update pipeline looks like:
New Document
↓
Processing
↓
Chunking
↓
Embeddings
↓
Index Update
↓
Available for Retrieval
This is particularly useful for information such as:
The knowledge pipeline therefore becomes an important part of ongoing maintenance.
Not every question should be answered from documents.
Some information is better retrieved directly from a business system.
For example:
"Where is my order?"
The latest order status should generally come from the relevant business system rather than an old PDF.
A more advanced application can combine RAG with APIs:
User Question
↓
AI Router
↙ ↘
RAG Search API
↓ ↓
Documentation Live Data
↘ ↙
AI Model
↓
Answer
This allows the application to combine static knowledge with live information.
RAG can also become the knowledge layer inside an AI agent.
For example:
"Check the company's return policy and process my eligible return."
The agent may:
This creates a broader architecture:
RAG + APIs + AI Agent + Business Systems
The technologies solve different parts of the workflow.
A proof of concept demonstrates that the idea works.
A production system must also consider:
A prototype might connect a few documents to an AI model.
A production RAG application may need to operate across thousands or millions of documents and serve many users securely.
The engineering requirements are therefore significantly different.
The model is not the business problem.
Start with the workflow.
Bad or outdated documents create bad retrieval results.
Chunking has a direct impact on retrieval quality.
Some queries benefit from exact keyword matching or structured filters.
More information does not automatically mean better answers.
Enterprise knowledge must respect user access.
The system must know how to respond when information is unavailable.
Retrieval quality should also be measured.
There is no single fixed price for RAG development.
Cost depends on factors such as:
A small internal knowledge assistant can be relatively simple.
An enterprise RAG platform with multiple data sources, strict permissions, real-time integrations, and high traffic requires considerably more engineering.
The best approach is to define the use case and architecture before estimating development cost.
Development time varies based on complexity.
A basic proof of concept may require only a limited number of components.
A production application can require additional work for:
Rather than estimating development from the phrase "RAG application," define the required features and workflow first.
A RAG application may be a strong candidate if:
It may not be necessary if the problem can be solved more simply with a conventional database query, search system, API, or automation workflow.
The goal should be useful AI, not AI for its own sake.
A production RAG application requires expertise across AI and software engineering.
A development partner can help with:
MYST International combines AI development with custom software development, web and mobile application development, and technology consulting, making it possible to approach RAG as part of a complete business software solution.
A typical RAG application needs a knowledge source, data-processing pipeline, document chunking, embeddings, a searchable knowledge store, retrieval logic, a language model, application logic, and appropriate security and evaluation.
Yes. RAG commonly works by connecting an existing language model to an external knowledge and retrieval system. The model itself does not necessarily need to be trained on the company's documents.
Yes. PDFs can be processed, their relevant text extracted and divided into chunks, and those chunks can then be indexed for retrieval.
Yes. Website content can be collected and processed into a searchable knowledge source, provided the content can legally and technically be accessed and used.
No. Vector search is common in RAG systems, but the appropriate retrieval infrastructure depends on the application's requirements and existing technology stack.
Yes. A RAG application can be combined with APIs or database queries to access information that needs to be current rather than retrieved from static documents.
Yes. RAG can be useful for enterprise knowledge, documentation, support, and search applications, but enterprise deployments require appropriate authentication, authorization, monitoring, data governance, and evaluation.
Building a RAG application is not simply a matter of connecting documents to an AI model.
The real process begins with understanding the business problem and then designing a reliable information pipeline around it.
Good data → good retrieval → relevant context → controlled generation → reliable application.
Every stage matters.
A technically impressive language model cannot compensate for poor source data. A large knowledge base cannot compensate for ineffective retrieval. And accurate retrieval cannot compensate for missing security or poor application design.
The strongest RAG applications combine AI models, high-quality knowledge, effective retrieval, software engineering, security, and continuous evaluation.
